![MEAN WELL ELG-150-C2100B-3Y [12/12] Elg 150](/img/pdf.png)
MEAN WELL ELG-150-C2100B-3Y [12/12] Elg 150
![MEAN WELL ELG-150-C2100B-3Y [12/12] Elg 150](/views2/1688247/page12/bgc.png)
208
219
195
200±20
300±20
45.8
63
35.5
35
105
20
4- 4.5ψ
Please refer to : http://www.meanwell.com/manual.html
105~150W Constant Current Mode LED Driver
ELG-150-C series
INSTALLATION MANUAL
※ BE-Type
tc
: Max. Case Temperature
tc
SJOW 17AWGx3C
&H05RN-F 1.0mm
2
DIM-(Black)
DIM+( )Gray
AUX-(White)
AUX+( )Red
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx4C
&H05RN-F 1.0mm
2
AC/L(Brown)
AC/N(Blue)
※ 3Y Model (3-wire input)
PE (Green/Yellow)
tc
: Max. Case Temperature
tc
208
219
195
300±20
45.8
63
105
20
4- 4.5ψ
SJOW 17AWGx3C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
◎ Note1: Please connect the case to PE for the complete EMC deliverance and safety use.
◎ Note2: Please contact MEAN WELL for input wiring option with PE.
AC/L(Brown)
AC/N(Blue)
FG (Green/Yellow)
File Name:ELG-150-C-SPEC 2018-09-30
300±20
