1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
1
PS2_USB_PWR1
IDE1
CHA_FAN1
SPEAKER1
1
HD_AUDIO1
Intel
G31
Chipset
PANEL1
HDLED RESET
PLED PWRBTN
1
CMOS
Battery
4Mb
BIOS
1
AUDIO
CODEC
18.3cm (7.2 in)
24.4cm (9.6 in)
ATX12V1
Super
IO
FLOPPY1
1
2
4 5
7
6
8
9
10
12
13
14
11
15
16
17
1819
22
23
24
25
26
27
3
20
21
Intel
ICH7
FSB800
DDRII_1 (64 bit, 240-pin module)
FSB800
DDRII_2 (64 bit, 240-pin module)
SATAII_3
SATAII_1
SATAII_4
SATAII_2
PCIE1
LAN
PHY
USB 2.0
T: USB2
B: USB3
USB 2.0
T: USB0
B: USB1
Top:
RJ-45
COM1
PS2
Mouse
PS2
Keyboard
Top:
Line In
Center:
Line Out
Bottom:
Mic In
CPU_FAN1
1
USB6_7
28
PCIE2
PCI1
PCI2
1
USB4_5
1
LPT1
OC 800
1
1
1
FSB0
FSB1
VGA1
EUP_LAN
1
EUP_AUDIO1
1
CLRCMOS1
RoHS
FSB1600
DDR2 800
Dual Channel
29
EuP Ready
1 PS2_USB_PWR1 Jumper 16 USB 2.0 Header (USB6_7, Blue)
2 775-Pin CPU Socket 17 USB 2.0 Header (USB4_5, Blue)
3 North Bridge Controller 18 Chassis Fan Connector (CHA_FAN1)
4 CPU Fan Connector (CPU_FAN1) 19 Floppy Connector (FLOPPY1)
5 2 x 240-pin DDR2 DIMM Slots 20 EUP Audio Jumper (EUP_AUDIO1)
(Dual Channel: DDRII_1, DDRII_2; Yellow) 21 Front Panel Audio Header
6 ATX Power Connector (ATXPWR1) (HD_AUDIO1, Lime)
7 IDE1 Connector (IDE1, Blue) 22 EUP LAN Jumper (EUP_LAN1)
8 Clear CMOS Jumper (CLRCMOS1) 23 PCI Slots (PCI1- 2)
9 South Bridge Controller 24 BIOS SPI Chip
10 Third SATAII Connector (SATAII_3; Orange) 25 PCI Express x16 Slot (PCIE2)
11 Fourth SATAII Connector (SATAII_4; Orange) 26 PCI Express x1 Slot (PCIE1)
12 System Panel Header (PANEL1, Orange) 27 Print Port Header (LPT1, Purple)
13 Chassis Speaker Header (SPEAKER 1, Purple) 28 OC 800 / FSB0 / FSB1 Jumper
14 Primary SATAII Connector (SATAII_1; Red) 29 ATX 12V Connector (ATX12V1)
15 Secondary SATAII Connector (SATAII_2; Red)
