Hardware Monitor: CPU temperature sensing

Chassis temperature sensing

CPU overheat shutdown to protect CPU life

Voltage monitoring: +12V, +5V, +3V, Vcore

CPU fan tachometer

Chassis fan tachometer

PCI slots: 3 slots with PCI Specification 2.2

AGP slot (for G Pro only):

1 universal AGP slot, supports 3.3v / 1.5v, 4X / 2X / 1X

AGP card

AMR slot: 1 slot, supports ASRock AMR modem card

USB 2.0: 4 default USB ports and a set of header for two additional

USB ports upgrade

ASRock I/O

: PS/2: keyboard / mouse

RJ 45

4 rear default USB ports (USB 2.0)

1 VGA port

1 parallel port: ECP/EPP support

Audio Jack: Line Out/ Line In/ Microphone + Game port

BIOS: AMI legal BIOS

Supports “Plug and Play”

ACPI 1.1 compliance wake up events

Supports jumperfree

SMBIOS 2.3.1 support

CPU frequency stepless control

(only for advanced users’ reference)

OS: Windows 98SE / ME / 2000 / XP compliant

1. While CPU overheat is detected, the system will automatically shutdown. Please check

if the CPU fan on the motherboard functions properly before you resume the system.

2. Although G Pro/GV Pro offers stepless control, it is not recommended to perform over

clocking. Frequencies other than the recommended CPU bus frequency may cause

the instability of the system or damage the CPU.
