ASRock X570 Phantom Gaming X [14/110] English
![ASRock X570 Phantom Gaming X [14/110] English](/views2/1690224/page14/bge.png)
English
7
X570 Phantom Gaming X
•
1 x Dr. Debug with LED
•
1 x Power Button with LED
•
1 x Reset Button with LED
•
1 x Clear CMOS Button
BIOS
Feature
•
AMI UEFI Legal BIOS with GUI support
•
Supports “Plug and Play”
•
ACPI 5.1 compliance wake up events
•
Supports jumperfree
•
SMBIOS 2.3 support
•
CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_
CLDO, PERM VDDCR_SOC, +1.8V, VDDP Voltage Multi-
adjustment
Hardware
Monitor
•
Temperature Sensing: CPU, CPU/Water Pump, Chassis,
Chassis/Water Pump Fans
•
Fan Tachometer: CPU, CPU/Water Pump, Chassis, Chassis/
Water Pump Fans
•
Quiet Fan (Auto adjust chassis fan speed by CPU tempera-
ture): CPU, CPU/Water Pump, Chassis, Chassis/Water
Pump Fans
•
Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis,
Chassis/Water Pump Fans
•
Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, CPU VD-
DCR_SOC, DRAM, VPPM, PREM VDDCR_SOC, +1.8V,
VDDP
OS
•
Microso® Windows® 10 64-bit
Certica-
tions
•
FCC, CE
•
ErP/EuP ready (ErP/EuP ready power supply is required)
Please realize that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, applying Untied Overclocking Technology, or using third-party
overclocking tools. Overclocking may aect your system’s stability, or even cause damage to
the components and devices of your system. It should be done at your own risk and expense.
We are not responsible for possible damage caused by overclocking.
* For detailed product information, please visit our website:
http://www.asrock.com
