B450 Pro4 R2.0
3
English
Expansion
Slot
AMD Ryzen series CPUs (Matisse, Summit Ridge and Pinnacle
Ridge)
•
2 x PCI Express 3.0 x16 Slots (PCIE2: x16 mode; PCIE4: x4
mode)*
AMD Ryzen series CPUs (Picasso, Raven Ridge)
•
2 x PCI Express 3.0 x16 Slots (PCIE2: x8 mode; PCIE4: x4
mode)*
AMD Athlon series CPUs
•
2 x PCI Express 3.0 x16 Slots (PCIE2: x4 mode; PCIE4: x2
mode)*
* Supports NVMe SSD as boot disks
* If M2_1 is occupied, PCIE4 will be disabled.
•
4 x PCI Express 2.0 x1 Slots
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
**
** is feature is only supported with Ryzen Series CPUs
(Matisse, Summit Ridge, Pinnacle Ridge, Picasso and Raven
Ridge).
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
ree graphics output options: D-Sub, HDMI and
DisplayPort 1.2
•
Supports Triple Monitor
•
Supports HDMI 1.4 with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
