ASRock A320M/ac [29/75] A320m ac
![ASRock A320M/ac [29/75] A320m ac](/views2/1691312/page29/bg1d.png)
A320M/ac
23
English
Ryzen Series CPUs (Pinnacle Ridge):
Ryzen Series CPUs (Picasso):
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 2933
- SR 2933
DR - 2933
- DR 2933
SR SR 2933
DR DR 2933
UDIMM Memory Slot
Frequency
(Mhz)
A1 B1
SR - 2933
- SR 2933
DR - 2667
- DR 2667
SR SR 2933
DR DR 2667
