![ASRock A320M/ac [32/75] Expansion slots pci express slots](/views2/1691312/page32/bg20.png)
English
26
2.4 Expansion Slots (PCI Express Slots)
ere are 2 PCI Express slots on the motherboard.
PCIe slots:
PCIE1 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIe Slot Congurations
Before installing an expansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start
the installation.
CPU PCIE2
Ryzen series CPUs (Matisse) x16
Ryzen series CPUs (Pinnacle Ridge) x16
Ryzen series CPUs (Summit Ridge)
x16
Ryzen series CPUs (Picasso) x8
Ryzen series CPUs (Raven Ridge) x8
Athlon 2xxGE series APU x4
7
th
A-Series APUs x8
For a better thermal environment, please connect a chassis fan to the motherboard’s
chassis fan connector (CHA_FAN1 or CHA_FAN2 ) when using multiple graphics cards.
