BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
EZ Overclocking
Load Optimized CPU OC Setting [Press Enter]
CPU Configuration
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Boot Failure Guard
Advanced Clock Calibration
CPU Active Core Control
Boot Failure Guard Count
AMD Turbo Core Technology
AMD IO C-State Support
Processor Maximum Frequency
North Bridge
Processor Maximum Voltage
Maximum Frequency
x13.5 2700 MHZ
x10.0 20
1.325 V
00 MHz
[Auto]
[Enabled]
[3]
[Disabled]
[Auto]
[Enabled]
[Disabled]
Multiplier/Voltage Change
[Manual]
Load Optimized mGPU OC Setting [Press Enter]
Advanced Clock Calibration
This allows you to adjust Advanced Clock Calibration feature. The default value
is [Disabled]. Configuration options: [Disabled], [Auto], [All Cores] and [Per
Core]. If you select [All Cores], you will see the option “Value (All Cores)”.
Configuration options: [+12%] to [-12%]. If you select [Per Core], you will see
the options “Value (Core 0)”, “Value (Core 1)”, “Value (Core 2)” and “Value
(Core 3)”. Configuration options: [+12%] to [-12%].
AMD Turbo Core Technology
This item appears only when the processor you adopt supports this feature.
Use this to select enable or disable AMD Turbo Core Technology. Confi guration
options: [Auto] and [Disabled]. The default value is [Auto].
AMD IO C-State Support
This allows you to enable or disable AMD IO C-State Support. The default
value is [Enabled].
CPU Active Core Control
This allows you to adjust CPU Active Core Control feature. The configuration
options depend on the CPU core you adopt. The default value is [All Cores].
Processor Maximum Frequency
It will display Processor Maximum Frequency for reference.
North Bridge Maximum Frequency
It will display North Bridge Maximum Frequency for reference.
Processor Maximum Voltage
It will display Processor Maximum Voltage for reference.
Multiplier/Voltage Change
This item is set to [Auto] by default. If it is set to [Manual], you may adjust the
value of Processor Frequency and Processor Voltage. However, it is
recommended to keep the default value for system stability.
CPU Frequency Multiplier
For safety and system stability, it is not recommended to adjust the value of
this item.
