3838
3838
38
BIOS SETUP UTILITY
Main
Smart H/W Monitor Boot Security ExitAdvanced
Use [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
System Overview
System Time
System Date
[ :00:09]
[Mon 11/03/2008]
BIOS Version
Processor Type
Processor Speed
Microcode Update
L1 Cache Size
L2 Cache Size
Total Memory
DDRII1
DDRII2
DDRII3
DDRII4
L3 Cache Size
: A770DE P1.0
: AMD Phenom(tm) 8400 Triple-Core
Processor (64bit)
: 2100MHz
: 100F22/1000083
: 384KB
: 1536KB
: 2048KB
: 1024MB
Dual-Channel Memory Mode
: 512MB/333MHz (DDR2 667)
: None
: None
: 512MB/333MHz (DDR2 667)
17
3.1.23.1.2
3.1.23.1.2
3.1.2
Navigation KeysNavigation Keys
Navigation KeysNavigation Keys
Navigation Keys
Please check the following table for the function description of each navigation
key.
Navigation Key(s) Function Description
/ Moves cursor left or right to select Screens
/ Moves cursor up or down to select items
+ / - To change option for the selected items
<Enter> To bring up the selected screen
<F1> To display the General Help Screen
<F9> To load optimal default values for all the settings
<F10> To save changes and exit the BIOS SETUP UTILITY
<ESC> To jump to the Exit Screen or exit the current screen
3.23.2
3.23.2
3.2
Main ScreenMain Screen
Main ScreenMain Screen
Main Screen
When you enter the BIOS SETUP UTILITY, the Main screen will appear and display
the system overview.
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
