Processor Frequency
This option appears only when you adopt AM2 CPU. This item will show when
“Multiplier/Voltage Change” is set to [Manual]; otherwise, it will be hidden. The
range of the value depends on the CPU you adopt on this motherboard. However,
for system stability, it is not recommended to adjust the value of this item.
Processor Voltage
This option appears only when you adopt AM2 CPU. This item will show when
“Multiplier/Voltage Change” is set to [Manual]; otherwise, it will be hidden. The
range of the value depends on the CPU you adopt on this motherboard. However,
for safety and system stability, it is not recommended to adjust the value of
this item.
Processor Target Frequency
This option appears only when you adopt Phenom CPU. This item will show
when “Multiplier/Voltage Change” is set to [Manual]; otherwise, it will be hidden.
The range of the value depends on the CPU you adopt on this motherboard.
However, for system stability, it is not recommended to adjust the value of this
item.
North Bridge Target Frequency
This option appears only when you adopt Phenom CPU. This item will show
when “Multiplier/Voltage Change” is set to [Manual]; otherwise, it will be hidden.
The range of the value depends on the CPU you adopt on this motherboard.
However, for safety and system stability, it is not recommended to adjust the
value of this item.
CPU Frequency Multiplier
This option appears only when you adopt Phenom CPU. However, for safety
and system stability, it is not recommended to adjust the value of this item.
CPU Frequency Divider
This option appears only when you adopt Phenom CPU. However, for safety
and system stability, it is not recommended to adjust the value of this item.
BIOS SETUP UTILITY
CPU Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Cool'n'Quiet
Enhanced Halt State
L3 Cache Allocation
Boot Failure Guard
Processor Maximum Frequency
North Bridge
Processor Maximum Voltage
Maximum Frequency
Memory Clock
Flexibility Option
[Auto]
[Disabled]
x10.5 2100 MHZ
x9.0 1800 MHz
1.2500 V
[Auto]
[Enabled]
[Auto]
[Disabled]
[BSP Only]
Multiplier/Voltage Change
[Manual]
If AUTO, multiplier and
voltage will be left at the
rated frequency/voltage. If
Manual,
will be set based
on User Selection in Setup.
multiplier and
voltage
Processor Target Frequency
North Bridge Target Frequency
x10.5 2100 MHZ
x9.0 1800 MHz
