Processor Multiplier
This item will show when “Multiplier/Voltage Change” is set to [Manual];
otherwise, it will be hidden. You may set the value from [x8 1600 MHz] up
to [x25 5000 MHz] but no higher than the value of “Processor Maximum
Multiplier”. For example, if the value of “Processor Maximum Multiplier” is
[x11 2200 MHz], the actual value of multiplier will be [x11 2200 MHz] even if
you set this item to a value higher than [x11 2200 MHz]. However, for
system stability, it is not recommended to adjust the value of this item.
Processor Voltage
This item will show when “Multiplier/Voltage Change” is set to [Manual];
otherwise, it will be hidden. For safety and system stability, it is not recom-
mended to adjust the value of this item.
Memory Clock
This item can be set by the code using [Auto]. You can set one of the
standard values as listed: [200MHz (DDRII 400)], [266MHz (DDRII 533)],
[333MHz (DDRII 667)], and [400MHz (DDRII 800)].
Flexibility Option
The default value of this option is [Disabled]. It will allow better tolerance for
memory compatibility when it is set to [Enabled].
CAS Latency
Use this item to adjust the means of memory accessing. Configuration
options: [Auto], [2.0], [3.0], and [2.5].
TRAS
Use this to adjust TRAS values. Configuration options: [Auto], [5CLK], [6CLK],
[7CLK], [8CLK], [9CLK], [10CLK], [11CLK], [12CLK], [13CLK], [14CLK], and
[15CLK].
TRP
Use this to adjust TRP values. Configuration options: [Auto], [2CLK], [3CLK],
[4CLK], [5CLK], and [6CLK].
BIOS SETUP UTILITY
BIOS SETUP UTILITY
CPU Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Cool'n'Quiet
Boot Failure Guard
[Auto]
[Enabled]
[Enabled]
Memory Clock
Flexibility Option
CAS Latency
TRAS
TRP
[Auto]
[Auto]
[Auto]
[Auto]
[Disabled]
If AUTO, multiplier and
voltage will be left at the
rated frequency/voltage. If
Manual,
will be set based
on User Selection in Setup.
multiplier and
voltage
BIOS SETUP UTILITY
Processor Maximum Multiplier
Processor Maximum Voltage
x11 2200 MHz
1.450 V
Multiplier/Voltage Change
[Manual]
Processor Multiplier
Processor Voltage
[x11 2200 MHz]
[1.450V]
