MEAN WELL HBG-60-1050 [2/5] Series

SPECIFICATION

File Name:HBG-60-SPEC 2015-01-29

60W Single Output LED Power Supply

HBG-60 series

MODEL

HBG-60-1050

HBG-60-1400 HBG-60-2100

RATED CURRENT

CURRENT ACCURACY

OUTPUT

SETUP TIME

VOLTAGE RANGE Note.3

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

AC CURRENT

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

SHORT CIRCUIT

OVER TEMPERATURE

1050mA

1400mA

2100mA

±5.0%

57.75W

60.2W

60.9W

60V

500ms / 230VAC 1200ms / 115VAC at 95% load

90 ~ 295VAC 127 ~ 417VDC

47 ~ 63Hz

PF>0.97/115VAC, PF>0.95/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve)

91%

90% 90%

0.7A/115VAC 0.4A/230VAC 0.3A/277VAC

COLD START 45A(twidth= s measured at 50% Ipeak) at 230VAC100μ

<0.75mA / 240VAC

-40 ~ +70 (Refer to "Derating Curve")℃

20 ~ 95% RH non-condensing

-40 ~ +80 , 10 ~ 95% RH℃

±℃ ℃0.03%/ (0 ~ 60 )

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

452Khrs min. MIL-HDBK-217F (25 )℃

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Derating may be needed under low input voltage. Please check the static characteristics for more details.

4. Please refer to "DRIVING METHODS OF LED MODULE".

5. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be

affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

6. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.

7. Constant current operation region is about 65%~100% rated output voltage, and the output power must be more than rated output power. This is

the suitable operation region for LED related applications, but please reconfirm special electrical requirements for some specific system design.

Enclosed type: 0.5Kg; 20pcs/ 11Kg/ 0.94CUFT PCB type:0.21Kg; 32pcs/ 7.7Kg/ 0.68CUFT

RATED POWER

NO LOAD OUTPUT VOLTAGE (max.)

ENVIRONMENT

SAFETY &

EMC

PROTECTION

Shut down o/p voltage, re-power on to recover

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC

I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH℃

SAFETY STANDARDS

Compliance to EN55015, EN61000-3-2 Class C ( 65% load) ; EN61000-3-3≧

CURRENT ADJ. RANGE Note.4

680 ~ 1050mA

910 ~ 1400mA 1360mA ~ 2100mA

RIPPLE & NOISE (max.) Note.2

EMC IMMUNITY

EMC EMISSION

CONSTANT CURRENT REGION Note.4

Enclosed type: 110mm * 60.5mm (D * H) PCB type: 99mm *26mm (D * H)ψψ

Hiccup mode, recovers automatically after fault condition is removed

Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, EN55024, light industry level(surge 2KV), criteria A

UL8750, CSA C22.2 No. 250.13-12, ENEC EN61347-1 & EN61347-2-13 independent, EN62384 approved

37 ~ 55V

28 ~ 43V 19 ~ 29V

5Vp-p

4Vp-p

3Vp-p

50V

35V

TOTAL HARMONIC DISTORTION

THD< 20% when output loading 65% at 115VAC/230VAC input and output loading 75% at 277VAC input≧≧
