BLOCK DIAGRAM

PFC fosc : 45~50KHz

PWM fosc : 60~130KHz

300W Constant Power Mode LED Driver

HBGC-300 series

File Name:HBGC-300-SPEC 2019-06-24

5200mA, 58V

8670mA, 34.8V

8670mA, 29V

312mA, 29V

312mA, 58V

2600mA, 58V

5200mA, 29V

25V

30V

35V

40V

45V

50V

55V

60V

0mA 1100mA 2200mA 3300mA 4400mA 5500mA 6600mA 7700mA 8800mA

156mA, 116V

4330mA, 69.6V

4330mA, 58V

156mA, 58V

1300mA, 116V

2600mA, 116V

2600mA, 58V

50V

60V

70V

80V

90V

100V

110V

120V

0mA 550mA 1100mA 1650mA 2200mA 2750mA 3300mA 3850mA 4400mA

78m A, 232V

1300m A, 232V

2170m A, 139.2V

2170m A, 116V

78m A, 116V

650m A, 232V

1300m A, 116V

100V

120V

140V

160V

180V

200V

220V

240V

0mA 300mA 600mA 900mA 1200mA 1500m A 1800mA 2100mA 2400m A

DRIVING METHODS OF LED MODULE

※ -I V Operating Area

◎ HBGC-300-L ◎ HBGC-300-M

◎ HBGC-300-H

Operational Region

High Performance Region

Operational Region

High Performance Region

Operational Region

High Performance Region

DETECTION

PWM

CIRCUIT

O.L.P.

EMI FILTER

RECTIFIERS

POWER

SWITCHING

FILTER

RECTIFIERS

-V

I/P

CONTROL

O.V.P.

PFC

CIRCUIT

PFC

CONTROL

O.T.P.

O.C.P.

DIM+

DIM-

(AB Type)
