2
ASRock FM2A85X Extreme4 Motherboard
English
Motherboard Layout
1 Power Fan Connector (PWR_FAN1) 22 Power Switch (PWRBTN)
2 ATX 12V Power Connector (ATX12V1) 23 Chassis Speaker Header (SPEAKER1)
3 CPU Heatsink Retention Module 24 Chassis Fan Connector (CHA_FAN1)
4 CPU Socket 25 Infrared Module Header (IR1)
5 CPU Fan Connector (CPU_FAN1) 26 Power LED Header (PLED1)
6 CPU Fan Connector (CPU_FAN2) 27 Clear CMOS Jumper (CLRCMOS1)
7 2 x 240-pin DDR3 DIMM Slots 28 USB 2.0 Header (USB7_8)
(Dual Channel A: DDR3_A1, DDR3_B1) 29 USB 2.0 Header (USB5_6)
8 2 x 240-pin DDR3 DIMM Slots 30 USB 2.0 Header (USB3_4)
(Dual Channel B: DDR3_A2, DDR3_B2) 31 Consumer Infrared Module Header (CIR1)
9 ATX Power Connector (ATXPWR1) 32 COM Port Header (COM1)
10 USB 3.0 Header (USB3_7_8) 33 HDMI_SPDIF Header (HDMI_SPDIF1)
11 Southbridge Controller 34 Front Panel Audio Header (HD_AUDIO1)
12 SATA3 Connector (SATA3_2) 35 PCI Slot (PCI3)
13 SATA3 Connector (SATA3_1) 36 PCI Slot (PCI2)
14 SATA3 Connector (SATA3_3) 37 SPI Flash Memory (64Mb)
15 SATA3 Connector (SATA3_4) 38 PCI Express 2.0 x16 Slot (PCIE4)
16 SATA3 Connector (SATA3_6) 39 PCI Slot (PCI1)
17 SATA3 Connector (SATA3_7) 40 PCI Express 2.0 x1 Slot (PCIE3)
18 Dr. Debug (LED) 41 PCI Express 2.0 x16 Slot (PCIE2)
19 SATA3 Connector (SATA3_5) 42 PCI Express 2.0 x1 Slot (PCIE1)
20 Reset Switch (RSTBTN) 43 Chassis Fan Connector (CHA_FAN2)
21 System Panel Header (PANEL1) 44 Chassis Fan Connector (CHA_FAN3)
Super
I/O
CMOS
BATTERY
ATXPWR1
AMD
A85X
(Hudson-D4)
Chipset
PCIE1
PCI1
LAN
AUDIO
CODEC
CPU_FAN1
64Mb
BIOS
PCIE2
CPU_FAN2
FM2A85X Extreme4
DDR3 2600+
ATX12V1
SOCKET FM2
PCIE4
Dr.
Debug
DDR3_A1 (64 bit, 240-pin module)
DDR3_A2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
PWR_FAN1
CHA_FAN3
CHA_FAN2
PCIE3
PCI2
PCI3
Dual Graphics
1
CLRCMOS1
PWRBTN
RSTBTN
HDLED RESET
PLED PWRBTN
1
PANEL1
SATA3_5
SATA3_4
SATA3_2
SATA3_3
SATA3_1
IR1
1
CHA_FAN1
SPEAKER1
1
PLED1
1
HD_AUDIO1
1
1
HDMI_SPDIF1
COM1
1
1
USB3_4
CIR1
1
1
USB5_6
1
USB7_8
Top:
CTR BASS
Center:
REAR SPK
Bottom:
Optical
SPDIF
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
Top:
RJ-45
USB 3.0
T: U SB 1
B: USB2
Ps2
Keyboard/
Mouse
VGA1
DVI1
USB 3.0
T:USB3
B: USB4
HDMI1
Clr
CMOS
USB 2.0
T:USB1
B: USB2
eSATA1
USB 3.0
T: U SB 5
B: USB6
USB3_7_8
X
Fast USB
X
Fast RAM
X
Fast LAN
RoHS
ErP/EuP Ready
DX11
Front USB 3.0
6
7
1
2
4
3
5
8
9
10
11
12
13
14
15
18
19
20
21
22
23
24
25
26
2728
29
3031
32
33
34
35
36
37
38
39
40
41
42
43
44
SATA3_7
SATA3_6
16
17
