3
English
FM2A58M-VG3+
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5 ATX Power Connector (ATXPWR1)
6 SATA2 Connector (SATA_3)
7 SATA2 Connector (SATA_4)
8 SATA2 Connector (SATA_1)
9 SATA2 Connector (SATA_2)
10 Chassis Fan Connector (CHA_FAN1)
11 Chassis Speaker Header (SPEAKER1)
12 System Panel Header (PANEL1)
13 Clear CMOS Jumper (CLRCMOS1)
14 USB 2.0 Header (USB_6_7)
15 USB 2.0 Header (USB_4_5)
16 COM Port Header (COM1)
17 TPM Header (TPMS1)
18 Print Port Header (LPT1)
19 Front Panel Audio Header (HD_AUDIO1)
20 Chassis Intrusion Header (CI1)
