3.4 Advanced Screen
In this section, you may set the congurations for the following items: CPU Congu-
ration, Nouth Bridge Conguration, South Bridge Conguration, Storage Congura-
tion, ACPI Conguration and USB Conguration.
Setting wrong values in this section may cause
the system to malfunction.
