66
66
6
1.21.2
1.21.2
1.2
SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Platform: ATX Form Factor: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm
CPU: 754-Pin Socket Supporting advanced 64-bit AMD Athlon
TM
64
and 32-bit / 64-bit Sempron Processors
Supports AMD’s Cool ‘n’ Quiet
TM
Technology (see CAUTION 1)
Chipsets: Bridge: nVidia nForce3 250 Series
Supports Untied Overclocking Technology
(see CAUTION 2)
Supports USB 2.0, ATA 133, SATA 1.5Gb/s
Memory: 2 x DDR DIMM Slots: DDR1 and DDR2
Support PC3200 (DDR400) / PC2700 (DDR333) /
PC2100 (DDR266), Max. 2GB
IDE: IDE1: ATA 133 / Ultra DMA Mode 6
IDE2: ATA 133 / Ultra DMA Mode 6
Supports up to 4 IDE Devices
Serial ATA: 2 x SATA Connectors
Supports up to 2 SATA Devices at 1.5Gb/s Data Transfer Rate
(Not Support “Hot Plug” function)
Floppy Port: Supports up to 2 Floppy Disk Drives
Audio: 7.1 channels AC’97 Audio
LAN: Speed: 802.3u (10/100 Ethernet), Supports Wake-On-LAN
Hardware Monitor: CPU Temperature Sensing
Motherboard Temperature Sensing
CPU Overheat Shutdown to Protect CPU Life
(ASRock U-COP)(see CAUTION 3)
CPU Fan Tachometer
Chassis Fan Tachometer
Voltage Monitoring: +12V, +5V, +3.3V, Vcore
Future CPU Port: Supports CPU upgrade from AMD 754-Pin CPU to AMD 939-Pin
CPU or other future CPU, such as 940-Pin CPU (M2)
(see page 13 for details)
PCI Slots: 4 x PCI Slots, PCI Specification 2.2
AGP Slot: 1 x AGP Slot
Supports 1.5V, 8X / 4X AGP Card (see CAUTION 4)
USB 2.0: 8 USB 2.0 Ports:
4 Ready-to-Use USB 2.0 Ports on the I/O Panel
Plus 2 On-Board Headers Supporting 4 Extra USB 2.0 Ports
(see CAUTION 5)
