DRAM tFAW

This controls the number of DRAM clocks for TFAW. Configuration options:

[0T] to [15T] for DDR3. The default value is [Auto].

VCORE Voltage

Use this to select VCORE Voltage. Configuration options: [Auto], [1.265V]

to [1.325V]. The default value of this feature is [Auto].

VCCM(DRAM) Voltage

Use this to select VCCM(DRAM) Voltage. Configuration options: [1.48V] to

[1.88V] for DDR3, [1.80V] to [2.21V] for DDR2. The default value of this

feature is [Auto].

Chipset Voltage

Use this to select chipset Voltage. Configuration options: [Auto], [1.20V]

to [1.35V]. The default value of this feature is [Auto].

VTT Voltage

Use this to select VTT Voltage. Configuration options: [Auto], [1.05V] to

[1.10V]. The default value of this feature is [Auto].

Would you like to save current setting user defaults?

In this option, you are allowed to load and save three user defaults

according to your own requirements.
