2828
2828
28
3.4.23.4.2
3.4.23.4.2
3.4.2
Chipset ConfigurationChipset Configuration
Chipset ConfigurationChipset Configuration
Chipset Configuration
BIOS SETUP UTILITY
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Chipset Settings
Primary Graphics Adapter
Onboard VGA Share Memory
PCIE Target Link Speed
OnBoard Lan
Onboard HD Audio
Front Panel
[Auto]
[Auto]
[Enabled]
[Auto]
[Auto]
Select Screen
Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
F9 Load Defaults
Advanced
[PCI]
Select the type of
primary VGA in case
of multiple video
controllers.
Primary Graphics Adapter
This item shows the primary graphics adapter. The default value is [PCI].
Configuration options: [Onboard], [PCI] and [PCI Express].
Onboard VGA Share Memory
This allows you to set onboard VGA share memory feature. The default
value is [Auto]. Configuration options: [Auto], [16MB], [32MB], [64MB],
[128MB], [256MB] and [512MB].
PCIE Target Link Speed
Use this item to set PCIE target link speed. Configuration options: [Auto]
and [Force Gen1]. The default value is [Auto].
OnBoard Lan
This allows you to enable or disable the “OnBoard Lan” feature.
Onboard HD Audio
Select [Auto], [Enabled] or [Disabled] for the onboard HD Audio feature. If
you select [Auto], the onboard HD Audio will be disabled when PCI Sound
Card is plugged.
Front Panel
Select [Auto] or [Disabled] for the onboard HD Audio Front Panel.
