1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
1 Power Fan Connector (PWR_FAN1) 13 Chassis Speaker Header (SPEAKER 1, White)
2 PS2_USB_PWR1 Jumper 14 Clear CMOS Jumper (CLRCMOS1)
3 ATX Power Connector (ATXPWR1) 15 PCI Slot (PCI1)
4 CPU Fan 16 PCI Express 2.0 x16 Slot (PCIE1)
5 CPU Heatsink 17 USB_PWR3 Jumper
6 2 x 240-pin DDR2 DIMM Slots 18 Front Panel Audio Header
(DDRII_1, DDRII_2; Yellow) (HD_AUDIO1, White)
7 1 x 240-pin DDR3 DIMM Slot (DDR3_1; Blue) 19 Primary SATAII Connector (SATAII_1; Blue)
8 USB 2.0 Header (USB6_7, Blue) 20 Secondary SATAII Connector (SATAII_2; Blue)
9 USB 2.0 Header (USB4_5, Blue) 21 VIA VX900 A3 Chipset
10 BIOS SPI Chip 22 USB_PWR2 Jumper
11 Chassis Fan Connector (CHA_FAN1) 23 CPU Fan Connector (CPU_FAN1)
12 System Panel Header (PANEL1, White)
1
PS2_USB_PWR1
SPEAKER1
1
HD_AUDIO1
PANE L 1
HDLED RESET
PLED PWRBTN
1
CMOS
Battery
4Mb
BIOS
1
AUDIO
CODEC
17.0cm (6.7 in)
21.6cm (8.5 in)
Super
IO
1
2
4
5
7
6
8
9
10
12
13
14
11
15
16
17
18
3
FSB800
DDRII_1 (64 bit, 240-pin module)
FSB800
DDRII_2 (64 bit, 240-pin module)
SATAII_1
SATAII_2
LAN
PHY
USB 2.0
T: U S B 0
B: USB1
Top:
RJ-45
PARALLEL PORT
VGA1
Top:
Line In
Center:
Line Out
Bottom:
Mic In
1
USB6_7
PCI1
1
USB4_5
RoHS
PCI Express 2.0
ErP/EuP Ready
USB 2.0
T: USB 2
B: USB3
COM1
Designed in Taipei
FSB800
DDR3_1 (64 bit, 240-pin module)
PS2
Mouse
PS2
Keyboard
PCIE1
CHA_FAN1
PWR_FAN1
CPU_FAN1
1
USB_PWR2
1
USB_PWR3
CLRCMOS1
PV530A
DDR2
DDR3
19
20
21
22
23
