BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Select the over clock
mode.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
OC Tweaker Settings
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Boot Failure Guard
Spread Spectrum
Boot Failure Guard Count
[Enabled]
[3]
[Auto]
VCORE Voltage
VCCM(DRAM) Voltage
Chipset Voltage
VTT Voltage
[Auto]
[Auto]
[Auto]
[Auto]
CPU Ratio Setting
DRAM Frequency
[9]
[Auto]
DRAM Configuration
3.33.3
3.33.3
3.3
OC TOC T
OC TOC T
OC T
weakweak
weakweak
weak
er Screener Screen
er Screener Screen
er Screen
In the OC Tweaker screen, you can set up overclocking features.
Overclock Mode
Use this to select Overclock Mode. The default value is [Auto]. Configura-
tion options: [Auto], [CPU, PCIE, Sync.], [CPU, PCIE, Async.] and [Optimized].
CPU Frequency (MHz)
Use this option to adjust CPU frequency.
PCIE Frequency (MHz)
Use this option to adjust PCIE frequency.
Boot Failure Guard
Enable or disable the feature of Boot Failure Guard.
Boot Failure Guard Count
Enable or disable the feature of Boot Failure Guard Count.
Spread Spectrum
This item should always be [Auto] for better system stability.
CPU Ratio Setting
You may use this item to set the ratio between CPU core clock and the FSB
frequency.
DRAM Frequency
If [Auto] is selected, the motherboard will detect the memory module(s)
inserted and assigns appropriate frequency automatically. You may select
[Auto], [400MHz DDR3_800] for DDR3 memory modules, or [Auto], [266MHz
DDR2_533], [333MHz DDR2_667], [400MHz DDR2_800] for DDR2 memory
modules.
