JR1 JL1

2-pin jumper

JR1(see p.10 No. 22)

JL1(see p.10 No. 21)

Note: If the jumpers JL1 and JR1 are short (see the figure above), both front

panel and rear panel audio connectors can work.

Clear CMOS

(CLRCMOS1, 2-pin jumper)

(see p.10 No. 11)

Note: CLRCMOS1 allows you to clear the data in CMOS. The data in CMOS includes

system setup information such as system password, date, time, and system

setup parameters. To clear and reset the system parameters to default setup,

please turn off the computer and unplug the power cord from the power

supply. After waiting for 15 seconds, use a jumper cap to short 2 pins on

CLRCMOS1 for 5 seconds.
