2121

2.72.7

2.7

Driver Installation GuideDriver Installation Guide

Driver Installation Guide

To install the drivers to your system, please insert the support CD to your optical

drive first. Then, the drivers compatible to your system can be auto-detected and

listed on the support CD driver page. Please follow the order from up to bottom

side to install those required drivers. Therefore, the drivers you install can work

properly.
