26
Chipset Configuration
AGP Mode
This feature will be set to [Auto] as default.
AGP Aperture Size
It refers to a section of the PCI memory address range used for graphics
memory. It is recommended to leave this field at the default value unless the
installed AGP card’s specification requires other sizes.
AGP Fast Write
This allows you to enable or disable the feature of AGP fast write protocol
support.
PCI Delay Transaction
Enable PCI Delay Transaction feature will free the PCI Bus when the CPU is
accessing 8-bit ISA cards. Disable this feature when using ISA cards that are
not PCI 2.1 compliant.
USB Controller
Use this to enable or disable the use of USB controller.
USB Device Legacy Support
Use this to enable or disable the support to emulate legacy I/O devices such as
mouse, keyboard,... etc.
DRAM CAS# Latency
This is used to adjust the means of memory accessing. Configuration options:
[Auto], [2T], [2.5T], [3T]. It is recommended to leave this field as [Auto] unless the
installed DRAM’s specification requires other value.
V-Link Speed
This feature allows you to speed up the V-Link speed. The default value is
[Normal].
AMIBIOS SETUP UTILITY - VERSION 3.31a
Advanced
AGP Mode
AGP Aperture Size
AGP Fast Write
PCI Delay Transaction
USB Controller
USB Device Legacy Support
DRAM CAS# Latency
Over Vcore Voltage
VCCM Voltage
AGP Voltage
V-Link Speed
[ Setup Help ]
F1:Help
Esc:Previous Menu
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
Chipset Configuration
64MB
Disabled
Disabled
Enabled
Disabled
Auto
Disabled
Auto
Auto
Normal
<Enter> to select [4X],
[2X], [1X] as the AGP
mode.
Auto
