7
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/s)
Front I/O
Front USB 1 x USB2.0 Type-A
Front Audio
1 x Mic-In & Line-Out Combo Jack
Front
DisplayPort
1 (CPU integrated graphics)
Rear I/O
HDMI 0
DisplayPort 4 (4K@60Hz with MXM Graphics Card)
Ethernet 2
USB 4 x USB 3.0 Type-A
Audio
0
Serial 0
PS2 0
Power 1 x 4-pin DC_IN Jack
Internal
Connector
USB 2 x USB 1.1/2.0 (1 x 2.54 pitch header)
LVDS/
Inverter
0/0
eDP 1 (CPU integrated graphics)
VGA 0
Serial 2 x 2.00 pitch COM (support RS-232 only)
SATA
- 2 x SATA3.0
- 1 x M.2 Key M Type 2242/ 2260/2280
(SATA shared with PCIe x4)
mPCIe 0
Parallel 0
mSATA 0
IrDA 0
GPIO 0
SATA PWR
Output
0
Speaker
Header
0
SPDIF 0
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
