ASRock MXM IPC-H110 [6/42] Specifications
![ASRock MXM IPC-H110 [6/42] Specifications](/views2/1693181/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Micro-STX (5.8-in x 7.4-in)
Processor
System
CPU
Supports 7
th
/6
th
Generation Core™ i7/Core™
i5/Core™ i3/Pentium
®
/Celeron
®
Processors
(LGA1151, Kaby Lake / Skylake)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset Intel
®
H110
BIOS UEFI
Expansion
Slot
PCIe 0
Mini-PCIe 0
MXM 1
M.2
- 1 x M.2 (KEY E, 2230) with PCIe x1 and USB
2.0 for Wireless
- 1 x M.2 (KEY M, 2242/2260/2280) with PCIe
x4 and SATA3 for SSD
Memory
Technology Dual Channel DDR4 2400 MHz
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller
- CPU integrated graphics to support 1 x DP
+ 1 x eDP (Gen9 Intel
®
Graphics, Support for
DirectX 11/12, OpenCL 2.0)
- Add on MXM Graphic Card (Type B) to support
4 x DP NVIDIA
®
GeForce GTX 1060/1070/1080
VRAM Shared Memory
VGA No
DVI No
LVDS No
HDMI No
DisplayPort
1 x supports max resolution up to 4K@60Hz
(CPU integrated graphics), 4 x supports max
resolution up to 4K@60Hz (MXM Graphics
Card)
MultiDisplay Hexa Display
Ethernet
Ethernet 10/100/1000 Mbps
Controller 1 x Intel
®
I219V + 1 x Intel
®
I210
Connector 2 x RJ-45
