7
Rear I/O
VGA N/A
DVI N/A
HDMI N/A
DisplayPort 2 x DP
Ethernet 2
USB 4 x USB3.1
Audio 2 (Mic-in, Line-out)
Serial N/A
PS2 N/A
Internal
Connector
USB 4 x USB 2.0
LVDS/
inverter
N/A
eDP 1
VGA N/A
Serial
1 x COM(RS232/422/485), 3 x
COM(RS-232)
SATA 2 x SATA3 (6.0Gb/s)
GPIO N/A
SATA PWR
Output
1
Speaker
Header
1
TPM 1 x Header
Watchdog
Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR 19V DC-in (DC Jack/4-pin ATX PWR Con)
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power
input ready
Environment
Operating
Temp
0ºC – 60ºC
Storage
Temp
-40ºC – 85ºC
