ASRock IMB-196 [6/42] Specifications
![ASRock IMB-196 [6/42] Specifications](/views2/1693321/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
BGA Type for Intel
®
Core i7/i5/i3 (Skylake ULT
MCP)
Core
Number
(By CPU, Max 2)
Max Speed (By CPU)
L2 Cache (By CPU)
Chipset N/A
BIOS UEFI
Expansion
Slot
PCIe 0
Mini-PCIe
1 (full/half size, supports PCIe x1 and USB
devices)
mSATA 1 (Supports SATA devices only)
Memory
Technology Dual Channel DDR4 2133MHz SDRAM
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics 520
VRAM Shared Memory
VGA
(Optional)
Supports max. resolution 1920 x 1200
LVDS
Dual channel 24-bit co-lay with eDP, max
resolution 1920 x 1200 @ 60Hz
HDMI
Supports HDMI 2.0, max resolution 4096 x 2160
@ 60Hz
DVI N/A
DisplayPort
Supports DP 1.2, max resolution 4096 x 2160 @
60Hz
Multi Display Yes (Triple Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller
1 x Intel
®
I219LM
1 x Realtek RTL8111G
Connector 2 x RJ-45
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/s)
Rear I/O
VGA 0
DVI 0
HDMI 1
DisplayPort 1
