7
Serial 0
PS/2 0
Internal
Connector
USB 4 x USB 2.0 (2 x 2.54 pitch header)
LVDS/
inverter
0/0
eDP 1
VGA 0
Serial
4 x RS-232 (COM1 supports RS-
232/422/485)
SATA 2
mPCIe
1
Parallel 0
mSATA 1
IrDA 0
GPIO 4 x GPI, 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Interval 1,2…255 Sec
Power
Requirements
Input PWR
Only +19V DC-in (DC Jack / 4-pin ATX
PWR Con)
Power On
AT/ATX Supported
AT : Directly PWR on as power input ready
ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
