1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1151 for Intel
®
Core i7/i5/i3/Celeron
(Skylake-S)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L2 Cache (By CPU)
Chipset Intel
®
H110
BIOS UEFI
Expansion
Slot
PCIe 1 x PCIe x4 slot
Mini-PCIe 1 (half size)
mSATA 1
Memory
Technology Dual Channel DDR4 2133MHz SDRAM
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
Gen9 Graphics DX 11/12, OGL4.3/4.4
VRAM Shared Memory
VGA 0
LVDS 0
HDMI Supports HDMI 1.4a
DVI 0
DisplayPort Supports DP 1.1a
Multi Display Yes (Dual Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller
1 x Intel
®
I219V
1 x Realtek RTL8111G
Connector 2 x RJ-45
SATA
Max Data
Transfer
Rate
2 x SATA3 (6.0Gb/s)
Rear I/O
VGA 0
DVI 0
HDMI 2
DisplayPort 1
Ethernet 2
USB 4 x USB 3.0
Audio 2 (Mic-in. Line-out)
