SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/s)
Rear I/O
VGA 0
DVI
0
HDMI 2
DisplayPort 0
Ethernet 2
USB 4 x USB 3.0
Audio 2 (Mic-in. Line-out)
Serial
0
PS/2 0
Internal
Connector
USB 4 (2 x 2.54 pitch header USB 2.0 compliant)
LVDS/
inverter
1/1
eDP 0
VGA 1
Serial
4 x RS-232 (COM1, 2 support RS-
232/422/485)
SATA 2 x SATA3 (6.0Gb/s)
mPCIe 1
Parallel 0
mSATA 1
IrDA 0
GPIO 4 x GPI, 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output From Super I/O to drag RESETCON#
Interval 256 segments, 0,1,2…255sec/min
Power
Requirements
Input PWR
12V / 19~24V DC-in (DC Jack / 4-pin ATX
PWR Con, choose either of the two)
Power On
AT/ATX Supported
AT : Directly PWR on as power input ready
ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
