IMB-191:
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1151 for Intel
®
Core i7/i5/i3/Celeron
(Skylake-S)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset Intel
®
H110
BIOS UEFI
Expansion
Slot
PCIe 0
Mini-PCIe 1 (1 x half size)
mSATA 1
PCIe 1 x PCIe x4 slot
CFast Card
Socket
0
Memory
Technology Dual Channel DDR4 2133MHz SDRAM
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
Gen9 Graphics DX 11/12, OGL4.3/4.4
VRAM Shared Memory
VGA Supports max. resolution 1920 x 1200
LVDS Supports max resolution 1920 x 1080 2ch-24bit
HDMI
Supports HDMI 1.4a, max resolution 4096 x
2160 @ 24Hz, 24bpp
DVI 0
DisplayPort 0
Multi Display Yes (Dual Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller
1 x Intel
®
i210
1 x Intel
®
i219V
Connector 2 x RJ-45
