6
1.2 Specications
IMB-190:
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1151 for Intel
®
Core i7/i5/i3/Celeron
(Skylake-S)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset Intel
®
Q170
BIOS UEFI
Expansion
Slot
PCIe 0
Mini-PCIe
2 x Mini-PCIe (1 x full size colay with mSATA, 1
x half size, both with USB signal)
mSATA 1 (colay with full size Mini-PCIe)
PCIe 1 x PCIe x4 slot
CFast Card
Socket
0
Memory
Technology Dual Channel DDR4 2133MHz SDRAM
Max. 32GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
Gen9 Graphics DX 11/12, OGL4.3/4.4
VRAM Shared Memory
VGA Supports max. resolution 1920 x 1200
LVDS Supports max resolution 1920 x 1080 2ch-24bit
HDMI
HDMI1: Supports HDMI 2.0, max resolution
4096 x 2160 @ 60Hz, 24bpp
HDMI2,3: Supports HDMI 1.4a, max resolution
4096 x 2160 @ 24Hz, 24bpp / 3840 x 2160 @
30Hz, 24bpp
DVI 0
DisplayPort 0
Multi Display Yes (Triple Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller
1 x Intel
®
i210
1 x Intel
®
i219LM
Connector 2 x RJ-45
