11
USB 4 x USB 3.0 compliant
Audio 2 (Mic-In, Line-Out)
Serial 3 (RS-232/422/485)
PS/2 0
Internal
Connector
USB 6 (3 x USB Header 2.54mm pitch)
LVDS/
Inverter
0
VGA 0
Serial 4 (RS-232)
SATA
2 x SATA2 (3.0Gb/s), 2 x SATA3 (6.0Gb/s),
Support RAID 0/1/5/10
mPCIe 0
Parallel 0
mSATA 1 (shared)
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
0
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR ATX PWR (4 + 24)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
