10
1.4 Specications (IMB-181-DB)
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Socket LGA1150 for Intel
®
Core i7/i5/i3/Celeron
(Haswell)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L3 Cache (By CPU)
Chipset B85
BIOS UEFI
Expansion
Slot
PCI 0
Mini-PCIe 0
mSATA 1
PCIe 1 (x16)
CFast Card
Socket
0
Memory
Technology
Dual Channel DDR3 1066/1333/1600 MHz
SDRAM
Max. 16GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics (By CPU)
VRAM Shared Memory
VGA No
LVDS No
HDMI Supports HDMI 1.4a, max resolution 1920x1200
DVI Yes
DisplayPort Supports max resolution 2560x1600
Multi Display Yes (Three Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller
GbE LAN1:Intel
®
I210, LAN2: Intel
®
I217LM (with
v-Pro support)
Connector 2 x RJ-45
SATA
Max Data
Transfer
Rate
SATA2 (3.0Gb/S), SATA3 (6.0Gb/S), Supports
RAID 0/1/5/10
Rear I/O
VGA 0
DVI 1 (DVI-I)
HDMI 1
DisplayPort 1
Ethernet 2
