20
Digital Input / Output Power Select 1-2 : +12V
(3-pin JGPIO_PWR1)
2-3 : +5V
(see p.12, No. 17)
GPIO Default Setting 1-2 : +5V
(3-pin JGPIO_JP1)
2-3 : GND
(see p.12, No. 18)
mSATA Select Open : Use SATA_5
(2-pin MSATA_SEL1)
Close : Use mSATA
(see p.12, No. 19)
Power Loss Jumper Short : Power Loss
(2-pin PWR_LOSS1)
Close : no Power Loss
(see p.12, No. 23)
+5VSB_ATX
