ASRock IMB-157D [6/39] Specifications
![ASRock IMB-157D [6/39] Specifications](/views2/1693507/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
(Sink with Fan): IMB-157D (N4200) /
IMB-157J (J3455) / IMB-157M (E3940)
(Sink without Fan): IMB-157D-WF (N4200) /
IMB-157L (N3350) / IMB-157J-WF (J3455)
Core
Number
(By CPU, Max 4)
Max Speed (By CPU)
L2 Cache (By CPU)
L3 Cache (By CPU)
Chipset N/A
BIOS UEFI
Expansion
Slot
PCIe 1 x PCIe x1 slot
Mini-PCIe
1 (full/half size) with PCIe x1 and USB 2.0
(Shared)
mSATA 0
M.2
1 x M.2 (KEY M, 2242/2260) with SATA III signal
for SSD
1 x M.2 (KEY E, 2230) with PCIe x1 and USB 2.0
(Shared) for Wireless
Memory
Technology Dual Channel DDR3L 1867 MHz
Max. 16GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
HD Graphics
VRAM Shared Memory
VGA Supports Max resolution up to 1920 x 1200
DVI No
LVDS
Supports Max resolution up to 1920 x
1200@60Hz
HDMI
Supports HDMI, Max resolution up to 3840 x
2160@30Hz
DisplayPort No
MultiDisplay Yes (Triple Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller 2 x Realtek RTL8111G
Connector 2 x RJ-45
