7
Internal
Connector
USB 4 x USB2.0 (2 x headers)
LVDS 1 (BOM option with eDP)
eDP 1 (BOM option with LVDS)
VGA 1 (shared with VGA connector)
Serial 3 x COM (RS-232)
SATA 1 x SATA3 (6.0Gb/s)
Parallel 1 (shared with GPIO)
GPIO 8 x GPI, 8 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
SPI TPM 1 x header
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR
12V/19V~28V DC-in (20+4-pin ATX PWR
Con.)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
