ASRock IMB-158 [6/40] Specifications
![ASRock IMB-158 [6/40] Specifications](/views2/1693513/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU BGA1090 for Intel Gemini Lake SoC
Chipset N/A
BIOS UEFI
Expansion
Slot
PCIe 1 xPCIe x1
mini-PCIe 1 x Full/Half mini-PCIe with PCIe x1 and USB 2.0
M.2
1 x M.2 (Key E, 2230) with PCIe x1, CNVI and
USB2.0 for Wireless
1 x M.2 (Key M, 2242/2260/2280) with SATA3
for SSD
Memory
Technology Dual Channel DDR4 2400 MHz
Max 8GB
Socket 2 x SO-DIMM
Graphics
VGA Supports max resolution up to 1920x1200
DVI N/A
LVDS
Dual Channel 24-bit, max resolution up to
1920x1200@60Hz
eDP Max resolution up to 4096x2160@60Hz
HDMI N/A
DisplayPort Max resolution up to 4096x2160@60Hz
Multi Display Triple Display
Ethernet
Interface 10/100/1000 Mbps
Controller 2 x Realtck RTL8111H
Rear I/O
VGA 1
DVI N/A
HDMI N/A
DisplayPort 1 x DP++ 1.2
Ethernet 2
USB 4 x USB3.0
Audio Jack 2 (Mic-in, Line-out)
Serial 3 x COM (RS-232/422/485)
PS/2 2
