ASRock IMB-156D [37/37] Chapter 4 software support
![ASRock IMB-156J [37/37] Chapter 4 software support](/views2/1693515/page37/bg25.png)
37
Chapter 4: Software Support
4.1 Install Operating System
This motherboard supports Microsoft
®
Windows
®
operating systems: 10 32-bit / 10
64-bit / 8.1 64-bit / 8 64-bit / 7 32-bit / 7 64-bit. Because motherboard settings and
hardware options vary, use the setup procedures in this chapter for general refer-
ence only. Refer to your OS documentation for more information.
4.2 Support CD Information
The Support CD that came with the motherboard contains necessary drivers and
useful utilities that enhance the motherboard’s features.
4.2.1 Running The Support CD
To begin using the support CD, insert the CD into your CD-ROM drive. The
CD automatically displays the Main Menu if “AUTORUN” is enabled in your
computer. If the Main Menu did not appear automatically, locate and double
click on the le “ASRSETUP.EXE” from the BIN folder in the Support CD to
display the menus.
4.2.2 Drivers Menu
The Drivers Menu shows the available device’s drivers if the system detects
installed devices. Please install the necessary drivers to activate the devices.
4.2.3 Utilities Menu
The Utilities Menu shows the application software that the motherboard sup-
ports. Click on a specic item then follow the installation wizard to install it.
4.2.4 Contact Information
If you need to contact ASRockInd or want to know more about ASRockInd,
you’re welcome to visit ASRockInd’s website at http://www.asrockind.com; or
you may contact your dealer for further information.
