7
USB 4 (2 x USB 3.0, 2 x USB 2.0)
Audio 2 (Mic-in, Line-out)
Serial 0
PS/2 0
Internal
Connector
USB 6 (2 x USB 3.0, 4 x USB 2.0)
LVDS/
Inverter
1/1
VGA 1 (shared with rear I/O VGA COM)
Serial 5 (1 x RS-232/422/485, 4 x RS-232)
SATA
2 x SATA2 (3.0Gb/s)
mPCIe 1
Parallel 1
mSATA 1 (shared)
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR 9-19V DC-In (4-pin ATX PWR Con)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
