ASRock IMB-151D [6/38] Specifications
![ASRock IMB-151N [6/38] Specifications](/views2/1693529/page6/bg6.png)
6
1.2 Specications
Form
Factor
Dimensions Mini-ITX (6.7-in x 6.7-in)
Processor
System
CPU
Intel
®
Atom
TM
Baytrail-M/D Processor
Supports Hyper-Threading Technology
Core
Number
4
Max Speed (By CPU)
Cache 2MB
Chipset N/A
BIOS UEFI
Expansion
Slot
PCI 0
Mini-PCIe 1 (half size) + 1 (full size) shared with mSATA
mSATA 1 (shared with SATA2_2)
PCIe 1
CFast Card
Socket
0
Memory
Technology Dual Channel DDR3L-1333 MHz SDRAM
Max. 8GB
Socket 2 x SO-DIMM
Graphics
Controller Intel
®
Gen7 Intel
®
Graphics DX 11, OGL3.2
VRAM Shared Memory
VGA Supports max. resolution 1920x1200
LVDS
Dual Channel 24-bit, max resolution
1920x1200@60Hz
HDMI Supports HDMI 1.4a, max resolution 1920x1200
DVI No
DisplayPort No
Multi Display Yes (Dual Display)
Ethernet
Ethernet 10/100/1000 Mbps
Controller GbE LAN Realtek
Connector 1 x RJ-45
SATA
Max Data
Transfer
Rate
SATA2 (3.0Gb/s)
Rear I/O
VGA 1
DVI 0
HDMI 1
DisplayPort 0
Ethernet 1
