ROMED8-2T
Quick Installation Guide
www.asrockrack.com
8
LAN Port LED Indications
6 Install the Power Cables
IPMI LAN Port
ACT/LINK LED
SPEED LED
LAN Port
3V
3V
GND
GND
5V
5V
GND
PWROK_PS
5VSB
12V
12V
3V
121
13
24
3V
-12V
GND
PSON#
GND
GND
GND
5V
5V
5V
GND
N/A
7
Install the Memory
10
M.2_SSD (NGFF) Module Installation
System Panel Auxiliary Panel
9 Headers
LAN Port
1
2
3
Find the corresponding nut location to be used.
Move the stando based on the module type and
length.
Peel o the yellow protective lm on the nut. Hand
tighten the stando into the desired location.
Gently insert the M.2 module into the slot.
Tighten the screw with a screwdriver to secure
the module into place. Please do not overtighten
the screw.
4
5
4
8
1
5
12V
GND
5
Install the Processor and Heatsink
We recommend using the CPU Installation tool to avoid CPU pin-bent problem.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yel low 100M bps connection
On Link Green 1Gbps connection
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or
no link
Blinking Yellow Data Activity O 1Gbps connection
On Link Green 10Gbps connection
1
2
3
4
GND
12V
GND
SMB_CLK
SMB_Alert
CASEOPEN
1
SMB_DATA
+3VSB
LAN1_LINK
LED_PWR
LAN2_LINK
LED_PWR
+5VSB
GND
GND
LOCATORLED1+
LOCATORLED1-
LOCATORBTN#
System Fault LED-
A
B
C
D
System Fault LED+
E
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
3
2
4
5
BCDE
A
1
1
2
3
4
7
8
Locate the three torx screws on the CPU socket and
unscrew them according to the order A→B→C. Open
the rst retention cover.
Open the second bracket. Take out the internal
plastic cover.
Install CPU along with the carrier frame, do not
separate them. Please make sure the carrier frame
with CPU is closely attached to the rail frame while
inserting it.
Please make sure that the carrie r
frame with CPU is closely attached to
the rail frame while inserting it.
5
6
Install the carrier frame with CPU. Don’t separate them.
Carrier Frame with CPU
Rail Fra me
Close the bracket that holds the CPU. Close the
retention cover. Fasten the torx screw according to the
order A→B→C.
1
2
3
Unlock a DIMM slot by
pressing the module clip
outward.
Insert the memory module. Lock the clip.
M2_1 :
1 2 3 4
A B C D
3cm 4.2cm 6cm 8cm
Type2230 Type 224 2 Type2260 Ty pe 2280
M2_2 :
1 2 3 4 5
A B C D E
3cm 4.2cm 6cm 8cm 11cm
Type2230 Type 224 2 Type2260 Ty pe 2280 Type 22110
BCDE
A
BCDE
A
ABCDE
ABCDE
20
o
NUT1NUT2DE
TPM-SPI
SPI_WP
SPI_CS
MISO
RSMRST#
TPM_CS#
SPI PIRQ
SPI_RST
MOSI
SPI_CLK
+3.3V
GND
SPI_HOLD
1
X
ACT/LINK LED
SPEED LED
LAN Port
