ASRock ROME2D16-2T [8/91] Specifications
![ASRock ROME2D16-2T [8/91] Specifications](/views2/1694144/page8/bg8.png)
2 3
English
1.2 Specications
ROME2D16-2T
MB Physical Status
Form Factor SSI EEB
Dimension 12'' x 13'' (30.5 cm x 33.0 cm)
Processor System
CPU AMD EPYC™ 7002 Generation Processors
Socket 2 AMD Socket SP3
ermal Design
Power
ermal 225W (240W cTDP), Power 280W
CPLD LCMXO3LF-1300C-5BG
System Memory
Capacity 16 DIMM slots
Type - Eight Channel memory technology (1DPC)
- Support DDR4 3200/2666/2400 RDIMM, LRDIMM, 3DS
and NVDIMM
DIMM Size Per
DIMM
- RDIMM: 64GB, 32GB, 16GB, 8GB
- LRDIMM: 256GB, 128GB, 64GB, 32GB
- 3DS: 32GB, 16GB, 8GB
- NV DIMM: 32GB
DIMM
Frequency
- RDIMM: 3200MHz
- LRDIMM: 3200MHz
- 3DS: 3200MHz
- NVDIMM: 2666MHz
Voltage 1.2V
Expansion Slot
PCIe 4.0 x16 Slot1: Gen4 x16 link (CPU0) (Latch)
Slot3: Gen4 x16 link (CPU0) (Latch)
Slot4: Gen4 x16 link (CPU1) (Latch)
Slot5: Gen4 x16 link (CPU0) (Latch)
Slot6: Gen3 x16 link (CPU1) (Latch)
PCIe 4.0 x8 Slot2: Gen4 x8 link (CPU1) (Open-end)
Storage
SATA
Controller
EPYC™ 7002: 4 x SATA3
M.2 2 (M2_1: M-key (PCIe4.0 x4), Type 2242/2280/22110 from
CPU0; M2_2: M-key (PCIe4.0 x4 or SATA 6Gb/s), Type
2242/2280/22110 from CPU0)
OCulink 2 (PCIe4.0 x4 or 4 SATA 6Gb/s)
SlimSAS SLIM1: PCIe4.0 x8 or 8 SATA 6Gb/s; SLIM2: PCIe4.0 x8 or 8
SATA 6Gb/s)
