SiE-64 Names and Functions of The Indicator Lamps

Information 7

3. Names and Functions of The Indicator Lamps

3.1 Indicator Lamps and their Functions

Illustration

A “Ionizer needs cleaning” lamp

Flashes when the ionizer is dirty. See page 14.

B Timer settings

The selected OFF timer setting is lit. As time elapses, the remaining time is displayed on the remote

control. See page 14.

C Pollen/Cigarette smoke mode lamps

The corresponding lamp is lit when the unit is in either the pollen or cigarette smoke mode. See page 14.

D Inverter lamp

Lit while the inverter lamp is ON. The lamp can be turned OFF from on the remote control. See

page 14.

E Air Quality lamps

These lamps indicate how clean/dirty room air is.



Sharp fluctuations in temperature, humidity or odorless gases (carbon monoxide) can cause lamps to

light up and go out.



In the following cases, the lowest odor intensity is indicated for 2 minutes regardless of the true

intensity. There is nothing wrong with the equipment.



Immediately after reattaching the front panel.



Immediately after plugging in the power cable.

Constant Air Quality Monitoring

This unit monitors air quality even when OFF. Air quality is always displayed on the front panel. To turn the

display OFF in such a case, press once more on the remote control. See page 14.

F Auto mode lamp

Lit when the unit is in the auto mode. See page 14.

G Fan speed lamp

The lamp under the set fan speed is lit. See page 14.

H Mode selector (OFF) button

Every time the button is pressed, the mode switches as follow.

J Time to cut filter lamp/Reset button

This lamp lights up when it is time to change the ion filter. After fitting a new filter, press with ball-

point pen, etc. See page 22.

K Signal reception window

Signals from the remote controller are received through this window.
