BIOS Features
- Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRockRack Instant Flash
Hardware Monitor
Temperature
- CPU/DDR/LAN/Storage Temperature Sensing
- MB/Card Side Temperature Sensing
Fan
- CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
+1.1V,+1.0V, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®:
- Server 2019 (64 bit)
Linux:
- RedHat Enterprise Linux Server 7.4 (64 bit) / 7.6 (64 bit)
- CentOs 7.4 (64 bit) / 7.6 (64 bit)
- UBuntu 18.04 (64 bit)
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
*Install a CPU Fan when the airow through the heatsink is below 2CFM.
* For detailed product information, please visit our website: http://www.asrockrack.com
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility, this motherboard may fail Windows® Hardware Quality
Lab (WHQL) certication tests. If you install the drivers only, it will pass the WHQL tests.
