![ASRock E3C242D4U2-2T [10/90] English](/views2/1694717/page10/bga.png)
4 5
English
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
Fan Header 6(1CPU/3Front/2Rear)
ATX Power 1x (24-pin) + 1x (8-pin)
TR1 1
Buzzer 1
USB 3.1 Gen1
Header
1 (supports 2 USB 3.1 Gen1 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
M.2 (2230/2242/2260/2280, Supports PCIE3.0(X4)/SATA3)
ME/SPS
Recovery
1
BMC_SMB1 1
PSU_SMB1 1
SGPIO 2
80 Debug Port
LED
E3C246D4U2-2L2T : 1
E3C242D4U2-2T / E3C246D4U2-2T: N/A
ClearCMOS 1 (header and short pin)
OH/FanFail
LED
6 (Header)
System BIOS
BIOS Ty pe 256 Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side/TR1 Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®
- Server 2016 (64 bit)
- Server 2019 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.9 (64 bit) / 7.4 (64 bit)
- SUSE Enterprise Linux Server 12 SP1 (64 bit) /
12 SP3 (64 bit)
- Ubuntu 15.10 (64 bit) / 16.04 (64 bit)
*Please refer to our website for the latest OS support list.
