4 5
English
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, and
front LAN LED)
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
SATA DOM 1
TPM Header 1
SPI TPM Header 1
IPMB Header 1
Fan Header 7 (1CPU/4Front/2Rear)
ATX Power 1x (24-pin) + 1x (8-pin)+ 1x (4-pin)
TR1 1
Buzzer 1
USB 3.1 Gen1
Header
1 (supports 2 USB 3.1 Gen1 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
M.2 2 (M2_1: 2260/2280/22110, Supports PCIE3.0(x4);
M2_2:2260/2280, Supports PCIE3.0(x4))*
*e M.2 slot (M2_2) is shared with the PCIE5 slot (BOM option). When
M2_2 is populated with a M.2 PCIe module, PCIE5 is disabled.
ME/SPS
Recovery
1
BMC_SMB_1 1
PSU_SMB1 1
SGPIO 1
Front VGA 1
Front LAN LED 1
NMI Button 1
80 Debug Port
LED
1
ClearCMOS 1 (short pin)
OH/FanFail
LED
7 (header)
System BIOS
BIOS Ty pe 256 Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- MB/Card side/TR1 Temperature Sensing
