Z490D4U-2L2T / W480D4U Series
4 5
English
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
Fan - Chassis Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
V1.0M,+BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®
-Windows 10 (64 bit)
Linux®
- RedHat Enterprise Linux Server 7.7 (64 bit) / 8.1 (64 bit)
- CentOs 7.7 (64 bit) / 8.1 (64 bit)
- SUSE Enterprise Linux Server 12 SP5 (64 bit) / 15 SP1
(64 bit)
- Ubuntu 19.04 (64 bit) / 20.04 (64 bit)
Virtual
- VMWare® ESXi 7.0.0/ vSphere 7.0.0
*W480D4U Series support UEFI BOOT only.
*Z490D4U-2L2T supports Legacy and UEFI BOOT.
*e Intel Raid mode is not supported on the Linux system.
*Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
