Capacity Tables ED43-441
38 Packaged Air Conditioners UATY-K Series
7.4 Heating Capacity [60Hz]
UATY06KTAL
UATY06KYAL
UATY08KTAL
UATY08KYAL
(m³/min.)
(˚CDB)
(kW)
(kW)
Symbols:
AFR
EDB
TC
PI
: Air flow rate
: Entering dry bulb temp.
: Total heating capacity
: Power input
(Comp.+outdoor fan motor).
Notes:
1. Direct interpolation is permissible.
Do not extrapolate beyond the Operation Limits.
2. shows nominal capacities.
3. Capacities are based on the following conditions.
Outdoor air : 85% RH. However, the condition on nominal capacity is
7˚CDB/6˚CWB.
4. Above heating capacities include indoor fan motor heat.
3D014897A
AFR
47
52
62
EDB(˚C)
16.0
18.0
20.0
21.0
22.0
24.0
16.0
18.0
20.0
21.0
22.0
24.0
16.0
18.0
20.0
21.0
22.0
24.0
TC
13.5
13.5
13.5
13.6
13.6
13.6
13.5
13.5
13.5
13.5
13.5
13.6
13.6
13.5
13.5
13.5
13.5
13.5
PI
5.0
5.2
5.4
5.5
5.6
5.7
4.9
5.1
5.3
5.4
5.4
5.6
4.8
4.9
5.1
5.2
5.3
5.5
TC
15.5
15.5
15.5
15.5
15.5
15.5
15.6
15.6
15.5
15.5
15.5
15.5
15.6
15.6
15.6
15.5
15.5
15.5
PI
5.4
5.6
5.8
5.9
5.9
6.2
5.3
5.4
5.6
5.7
5.8
6.0
5.1
5.3
5.4
5.5
5.6
5.8
TC
18.2
18.2
18.1
18.1
18.1
18.0
18.3
18.2
18.2
18.1
18.1
18.1
18.3
18.3
18.2
18.2
18.2
18.1
PI
5.9
6.1
6.3
6.4
6.5
6.7
5.7
5.9
6.1
6.2
6.3
6.5
5.5
5.7
5.9
6.0
6.1
6.3
TC
20.2
20.2
20.1
20.0
20.0
19.9
20.3
20.2
20.1
20.1
20.1
20.0
20.4
20.3
20.2
20.2
20.2
20.1
PI
6.2
6.5
6.7
6.8
6.9
7.1
6.1
6.3
6.5
6.6
6.7
6.9
5.8
6.0
6.2
6.3
6.4
6.6
TC
–
–
22.7
22.6
22.5
22.4
–
–
22.8
23.0
22.7
22.6
–
–
23.0
22.9
22.9
22.7
PI
–
–
7.2
7.3
7.4
7.7
–
–
7.0
7.1
7.2
7.4
–
–
6.7
6.8
6.9
7.1
-5 0 6 10 15
Indoor air
Outdoor temp. (˚CWB)
3D014901A
(m³/min.)
(˚CDB)
(kW)
(kW)
Symbols:
AFR
EDB
TC
PI
: Air flow rate
: Entering dry bulb temp.
: Total heating capacity
: Power input
(Comp.+outdoor fan motor).
Notes:
1. Direct interpolation is permissible.
Do not extrapolate beyond the Operation Limits.
2. shows nominal capacities.
3. Capacities are based on the following conditions.
Outdoor air : 85% RH. However, the condition on nominal capacity is
7˚CDB/6˚CWB.
4. Above heating capacities include indoor fan motor heat.
